HRB-1503MH |
HRB-1503 |
HRB-1603MH |
HRB-1603 |
HRB-1703MH |
HRB-1703 |
| 50Hz |
60Hz |
50Hz |
60Hz |
50Hz |
60Hz |
50Hz |
60Hz |
50Hz |
60Hz |
50Hz |
60Hz |
| 상
PHASE |
3 |
3 |
3 |
3 |
3 |
3 |
| 모터 MOTOR |
HP |
- |
24.7 |
20.7 |
24.7 |
- |
30.0 |
24.7 |
30.0 |
- |
40.0 |
33.5 |
40.0 |
| Kw |
- |
18.5 |
15.5 |
18.5 |
- |
22.7 |
18.5 |
22.7 |
- |
30.0 |
25.0 |
30.0 |
| 토출 PRESSURE |
mmAq |
- |
1200 |
1300 |
1200 |
- |
1800 |
2000 |
1800 |
- |
2300 |
2600 |
2300 |
| 흡입 VACUUM |
mmAq |
- |
1100 |
1500 |
1100 |
- |
1800 |
2400 |
1800 |
- |
2500 |
2800 |
2500 |
최대풍량
MAX .
AIR FLOW |
㎥/min |
- |
40.0 |
33.0 |
40.0 |
- |
40.0 |
33.0 |
40.0 |
- |
40.0 |
33.0 |
40.0 |
| 전류 CURRENT |
220V |
A |
- |
65.5 |
50.0 |
65.5 |
- |
74.3 |
65.0 |
74.3 |
- |
91.8 |
75.0 |
91.8 |
| 380V |
A |
- |
37.8 |
28.8 |
37.8 |
- |
42.9 |
37.5 |
42.9 |
- |
53.0 |
43.3 |
53.0 |
소음
SOUND LEVEL |
dB(A) |
88 |
88 |
88 |
88 |
88 |
88 |
| 재질 MATERIAL |
IMPELLER |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
| CASING |
Cast Iron |
Cast Iron |
Cast Iron |
Cast Iron |
Cast Iron |
Cast Iron |
| 베어링 BEARING |
FRONT |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
| MIDDLE |
- |
- |
- |
- |
- |
- |
| REAR |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
6308ZC3 |
무게
WEIGHT |
Kg |
385 |
385 |
400 |
400 |
410 |
410 |
기동계급
STARTING
CLASS |
H |
H |
H |
H |
H |
H |
절연계급
INSULATION CLASS |
F |
F |
F |
F |
F |
F |
|
